U-POE is designed to power 802 3af PoE devices U-POE-AF delivers up to 15W of...

Specifikacija

Efficiency

84.25%

Power Adapter and Power Supply Features

PoE (802.3af)

Output Voltage

DC 48 V

Power Device Location

External

Built-in Devices

LED Indicator

Power Device Type

Power Adapter

Circuit Protection

Surge Protection

Rated Input Current

500 mA

Input Power Connectors Quantity

1

Input Power Connectors Type

IEC-320 C6

Output Power Connectors Quantity

2

Output Power Connectors Type

RJ-45

External Color

White

Warranty Products Returnable

Yes

Warranty Term (month)

12 month(s)

Warranty validation Criteria

Serial Number

Pack Weight Brutto (kg)

0.24 kg

Pack Weight Netto (kg)

0.18 kg

Pieces in pack

1

Box Weight Brutto (kg)

0.24 kg

Retail Packaging Net Weight Carton

0.24 kg

Retail Packaging Net Weight Plastic

0.24 kg

Packs in Box

1

Package Type

Box

Included Accessories

Quick Start Guide

Maximum Operating Ambient Temperature

40 °C

Minimum Operating Ambient Temperature

0 °C

Maximum Operating Humidity

95 %

Minimum Operating Humidity

10 %

Warranty Term Notes

24 months - for EU

Certifications

CE, FCC, IC, UL

Depth (mm)

46 mm

Height (mm)

86 mm

Width (mm)

33 mm

Nominal Weight

100 g

Input Voltage

AC 100-240 V

Input Frequency

50/60 Hz

Maximum Output Power

15 W

Maximum Non-Operating Ambient Temperature

70 °C

Minimum Non-Operating Ambient Temperature

-30 °C

Pack Length (mm)

86 mm

Pack Width (mm)

46 mm

Pack Height (mm)

33 mm
