Matična ploča AM5 Gigabyte B840M D2H DDR5 HDMI/M-2 - 1

Matična ploča AM5 Gigabyte B840M D2H DDR5 HDMI/M-2

Cena:
15.612,00 RSD
Bez takse
Rata od:2.602,00 RSD Rata je informativnog karaktera.Objašnjenje
Besplatna dostava preko 12.000 dinara. ( OSIM FOTO-PAPIRA )
Size chart
Size guide

SIZE GUIDE FOR ALL

TROUSERS, BERMUDAS, SHORTS, SKIRTS, MINI SKIRTS, SWIMMING COSTUMES…

SIZEWAISTHIPS
220,332
421,833,5
623,435,1
82536,7
1026,538,2
1228,139,8
1429,641,3
1631,242,9
1832,844,5
2034,346
SIZEWAISTHIPS
XS19,5-22,631,2-34,3
S22,6-25,734,3-37,4
M25,7-28,937,4-40,6
L28,9-3240,6-43,7
XL32-35,143,7-46,8
Dodaj za upoređivanje
Kategorije
Matične ploče Matične ploče za AMD socket
Reference
US_B840M D2H
Free Shipping Worldwide
Free 7 days return
Member discount
100% Secure checkout
























































































Model Gigabyte B840M D2H AM5 DDR5 Micro ATX Matična ploča
Procesorsko podnožje (Socket) AMD Socket AM5
Skup čipova (Chipset) AMD B840
Podrška za procesore AMD Ryzen 9000 Series Processors
AMD Ryzen 8000 Series Processors
AMD Ryzen 7000 Series Processors
Tip memorije (RAM) DDR5
Broj memorijskih slotova 2x 288-Pin DDR5
Podrška za memorije Support for DDR5 7600(O.C.) / 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules
2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
Podrška za grafiku - portovi Integrated Graphics Processor with AMD Radeon Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160 60Hz
Slotovi za proširenja 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen 9000/7000 Series Processors support PCIe 4.0 x16 mode
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.

Chipset:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
M.2 portovi 2x M.2 Socket 3
Čuvanje podataka - portovi 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:
AMD Ryzen 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 PCIe 3.0 x2 SSDs
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
SATA portovi 4x SATA 6Gb/s
LAN Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Zvuk (Audio) Realtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
USB portovi CPU:
- 2 x USB 3.2 Gen 1 ports on the back panel
CPU+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports on the back panel
Chipset:
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 4 x USB 2.0/1.1 ports available through the internal USB headers
Konektori na zadnjoj strani 1 x PS/2 keyboard/mouse port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x HDMI port
1 x Q-Flash Plus button
1 x RJ-45 port
3 x audio jacks
Unutrašnji konektori 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x CPU fan/water cooling pump header
1 x system fan header
2 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
4 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x reset jumper
1 x Clear CMOS jumper
Posebne mogućnosti Support for GIGABYTE Control Center (GCC)

Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control
Operativni sistem Windows 10; Windows 11
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Format Micro ATX

US_B840M D2H
